Pisces Bed-side Patient Monitor
12.1” color TFT LCD screen
8 waveform display,up to 12-lead ECG analysis
Powerful calculation(Hemodynamic,Dose,Oxygenation,Ventilation)
Pacemaker detection
ST & arrhythmia analysis
OxyCRGs
Various mounting solutions
Wired/Wireless CMS, support HL7 protocol to HIS
SpO2 pulse-tone modulation (Pitch Tone)
MEWS(Modified Early Warning Score)
Graphical & tabular trend review( 120 hours)
48h full disclosure wave review for each patient(stroed in SD card)
| Specifications | |
| Display | NIBP |
| 12.1” color TFT LCD touch Screen,resolution: 800 x 600 8 waveform display,12-leads ECG display |
Measurement method : Automatic oscillometric method Operating mode:Manual, automatic, continuous Measurement unit: mmHg/kPa selectable Typical measurement time: 20~40s Measurement type: Systolic, Diastolic,Mean Measurement range (mmHg) Range of Systolic pressure: Adult 40-270 Pediatric 40-200 Neonatal 40-135 Range of Diastolic pressure: Adult 10-210 Pediatric 10-150 Neonatal 10-95 Range of Mean pressure: Adult 20-230 Pediatric 20-165 Neonatal 20-105 Measurement accuracy Maximum average error: ±5mmHg Maximum standard deviation: 8mmHg Resolution: 1mmHg Interval:1,2,3,4,5,10,15,30,60,90,120,180,240,480minutes Overpressure protection: Software and hardware, double safety protection Cuff pressure range: 0-280mmHg |
| I/O | ECG |
| LAN: 1 standard RJ45 port WLAN: IEEE802.11b/g/n USB:2 USB connectors SD: 1 SD card socket Output:1 connector for nurse call,Defib sync analog output VGA: 1 VGA external socket (optional) |
Lead type :3-lead,5-lead,12-lead ECG waveform:2 channels,7 channels, 12 channels Display sensitivity: 2.5mm/mV (×0.25), 5mm/mV (×0.5), 10mm/mV (×1.0), 20mm/mV (×2.0) Wave sweep speed: 6.25mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s Bandwidth Diagnostic mode: 0.05Hz~100Hz Monitor mode: 0.5Hz~40Hz Surgery mode: 1Hz~20Hz Strong filter mode: 5Hz~20Hz CMRR>100dB Notch: 50/60Hz notch filter can be set to on or off Differential input impedance>5MΩ Electrode polarization voltage range: ±400mV Baseline recovery time<3s after defibrillation (in monitor andsurgery mode) Calibration signal:1mV (peak – peak), accuracy ±3% |
| TEMP | SpO2 (Northern ) |
| Accuracy: ±0.1℃ or ±0.2℃ °F（without probe） Measurement range: 5~50℃ （41~122°F） Channel：Two channels Resolution: 0.1℃ Parameters：T1,T2 and TD |
Measurement range : 0-100% Resolution: 1% Accuracy: ±2%（70-100%， Adult/Pediatric); ±3%（70-100%， Neonate); 0-69%,unspecified Refreshing Rate: 1s |
| RESP | Masimo SpO2 (optional) |
| Method:Trans-thoracic impedance Operation modes: Auto/Manual Measurement range: Adult:0~120 bmp; Neonate/Pediatric:0~150bpm Apnea alarm delay:10s,15s,20s,25s,30s,35s,40s Apnea alarm: Selectable Sweep speed: 6.25mm/s, 12.5mm/s, 25mm/s |
Measurement range : 0-100% Resolution: 1% Accuracy: ±2%（70-100%， Adult/Pediatric,non-motion,low prefusion); ±3%（70-100%， Neonate,non-motion); ±3%（70-100%， motion); 0-69%,unspecified Refreshing Rate: 1s |
| IBP(Optional) | Phasein IRMA TM Sidestream CO2 (optional) |
| Channel:2-channel or 4-channel ART: 0 to 300 mmHg PA: -6 to 120 mmHg CVP/RAP/LAP/ICP : -10 to 40 mmHg Measurement range: P1/P2 -50 to 300 mmHg Resolution:1mmHg Accuracy: ±2% or ±1mmHg, whichever is greater(without sensor) Sensitivity: 5uV/mmHg/V Impedance range: 300 to 3000Ω |
Warm-up time: Full accuracy within 10 seconds Sampling flow rate: 50ml/min(+/-10/min) Accuracy: 0~15% (±0.2% of the reading) 15~25%, unspecified Measurement Range: 0 -25% Rise time: 200ms,typical at 50ml/min flow rate Total response time: within 3 seconds(with 2m Momoline sampling line) AWRR Range: 0~150bpm |
