Patient Monitor | Gemini

Multiple parameter options satisfy the need for ICU,CCU,NICU.
Anesthesia Patient Monitor

Technical Specifications

Display

15.6”/17”/19”TFT Touch screen

Resolution: 1366 x 768

Number of traces: 12 waveforms

I/O

LAN: 1 standard  RJ45 port WLAN:IEEE 802.11b/g/n USB: 2 USB connectors

SD: 1 SD card socket

VGA: 1 VGA monitor connnector

Output:

1 connector for Nurse call,Defib Sync Analog Output

Lead type :3-lead,5-lead,12-lead

ECG waveform:2 channels,7 channels, 12 channels

Display sensitivity:

2.5mm/mV (×0.25), 5mm/mV (×0.5),

10mm/mV (×1.0), 20mm/mV (×2.0) Wave sweep speed:

6.25mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s

Bandwidth

Diagnostic mode: 0.05Hz~100Hz Monitor mode: 0.5Hz~40Hz Surgery mode: 1Hz~20Hz

Strong filter mode: 5Hz~20Hz

CMRR>100dB

Notch: 50/60Hz notch filter can be set to on or off

Differential input impedance>5MΩ

Electrode polarization voltage range: ±400mV

Baseline recovery time<3s after defibrillation (in monitor and surgery mode)

Calibration signal:1mV (peak – peak), accuracy ±3%

Configuration
5-lead ECG,SpO2,NIBP,TEMP, Resp,PR; Li-ion battery
Optional
12-Lead ECG,Masimo/Nellcor SpO2,2-IBP,C.O.,EtCO2,Multi-gas,BIS,NMT;
VGA,Thermal Recorder,Wired/Wireless CMS
Masimo SET SpO2 Bispectral Index by Aspect
Provides anti-motion and anti-low perfusion  SpO2 measurement.
Monitor the level of consciousness of the
patient under general anesthesia or sedation.
provides BIS, SQI, EMG, SR, SEF, TP, PC value
and EEG wave.
15.6”/17”/19” switchable TFT LCD Touch screen
Aluminum material shell
Fanless design allows for quite care environment
10 waveform display,up to 12-lead ECG analysis
Powerful calculation(Hemodynamic,Dose,Oxygenation,Ventilation)
SpO2 support PVI and PI，low perfusion 0.2%
Aspect BISx module, NMT(Organon TOF-Watch® )module optional
Wired/Wireless CMS, support HL7 protocol to HIS
SpO2 pulse-tone modulation (Pitch Tone)
VGA support external display
Graphical & tabular trend review( 120 hours)
48H full disclosure wave review for each patient(stroed in SD card)
Phasein IRMA

NMT
Intergrade Organon TOF-Watch® SX
Sidestream/Mainstream EtCO2
Allows selection of the modality best
suited to the application,monitoring
with infrared absorption technique,
Switchable screen
Support the external display
IBP
2-4 Channel, support IBP waveform
overlapping display
C.O.
Cardiac Output
12-Lead ECG
OxyCRG screen
4-IBP
Dynamic trends
